MIKROTIK Cloud Router Switch 304-4XG-IN (RouterOS L5), desktop enclosure
| Kód tovaru: | 2544861 |
|---|---|
| Výrobca: | MikroTik |
| PN kód: | CRS304-4XG-IN |
| EAN kód: | 4752224008954 |
| Záruka: | 24 mesiacov |
| Dostupnosť: | skladom (1) |
Specifications
Details
Product code CRS304-4XG-IN
Architecture ARM 64bit
CPU 98DX2528
CPU core count 2
CPU nominal frequency 1200 MHz
Switch chip model 98DX2528
RouterOS license 5
Operating System RouterOS v7
Size of RAM 512 MB
Storage size 32 MB
Storage type FLASH
MTBF Approximately 200"000 hours at 25C
Tested ambient temperature -40°C to 70°C
Powering
Details
Number of DC inputs 4 (DC jack, PoE-IN, 2-pin terminal)
DC jack input Voltage 12-57 V / 12-57 V
2-pin terminal input Voltage 12-57 V
Max power consumption 21 W
Max power consumption without attachments 15 W
Cooling type Passive
PoE in 802.3af/at
PoE in input Voltage 36-57 V
Ethernet
Details
10/100/1000 Ethernet ports 1
Number of 1G/2.5G/5G/10G Ethernet ports 4
Certification & Approvals
Details
Certification CE, EAC, ROHS
IP 20
Parametre
| Hĺbka jedn. balenie | 5.7 |
| Hmotnosť jedn. balenie | 0.892 |
| Počet kusov jedn. balenie | 1 |
| Rozmer xyz jedn. balenie | 13.9x26.9x5.7 |
| Šírka jedn. balenie | 13.9 |
| Typ balenia jedn. balenie | Balitelné |
| Výška jedn. balenie | 26.9 |
| Hmotnosť kartónu | 9.368 |
| Typ obalu kartón | Expedovatelné |
| Počet kusov v kartóne | 10 |
| Rozmer xyz kartónu | 17x58.2x30 |
| Typ balenia kartónu | Balitelné |
| Konektor DisplayPort | Ne |
| DP/mini DP (počet) | 0 |
| Konektor HDMI | Ne |
| Počet LAN portov | 5 |
| HDMI (počet) | 0 |
| Fanless switch | Ano |
| Rýchlosť LAN max. | 10 Gbps |
| Optika | Ne |
| Počet SFP portov | 0 |
| Počet QSFP portov | 0 |
| Počet QSFP+ portov | 0 |
| Počet SFP28 portov | 0 |
| Počet QSFP56/ QSFP28 | 0 |
| PoE | In (vstup) |
| PoE In standart | 802.3at (max. 33,6W) - PoE+ |
| PoE Out standard | Nepodporuje |
| PoE power budget (W) | Nevztahuje se |
